MIL-DTL-M16377/53D (date: 30 June 2014) outlines requirements for a kit designed to replace the incandescent #4546 lamp in the Battle Lanterns. The LED Retrofit Kit (also called Kit, Retro Lantern) consist of (1) Plexiglas or plastic lens (2) A LED mounted on a back plate that will fit in the place of the #4546 incandescent lamp (3) A emitter controller. The kit assembly must be watertight and meet the photometric test required by the mil spec.
JMC has developed Retrofit Kits to meet these requirements. Installing the kit is fast and easy. Simply remove the front cover of the lantern, remove the retaining ring holding the lamp in place, remove the lamp, insert the LED assembly and replace the ring and cover.
LED assemblies provide a reliable white light with less draw on the battery.
LED assemblies will provide emergency lighting for 30+ hours.
________________________________________
KIT, RETRO LANTERN WHITE LED RETROFIT KIT
NSN: 6230-01-531-7844
JMC P/N JMCLED-4W
Includes:
LED Assembly is a one piece unit consisting of:
(1) Reflector Plate
(2) Mounting Bracket with contact holder
(3) Emitter controller
(4) 4 White LEDs
(5) Lens
(6) Manual
________________________________________
KIT, RETRO LANTERN RED LED RETROFIT KIT
NSN: 6230-01-531-7845
JMC P/N: JMCLED-2R
Includes:
LED Assembly is a one piece unit consisting of:
(1) Reflector Plate
(2) Mounting Bracket with contact holder
(3) Emitter controller
(4) 2 Red LEDs
(5) Lens
(6) Manual
